Featured Items DS



File Number Make
425-5 DSM SD-54 2006  A rare opportunity to buy a very nice, well maintained and later model unit at a good price. New today, this rig would cost in the 1.25 MM range. This rig has only drilled 125 wells and It is a one owner unit that has been kept in a heated shop when not working in the field.
62' vertical free standing mast-- Stacked DD drawworks w/air clutches-20,000 lb maximum single line pull---Double 8" x 22 brake bands both drums--(6) part lines both drums---10"retractable rotary table--retracted table opening--(25" side to side and 26" front to back--Mechanically driven w/air clutch-Hyd pull downs--Hydraulic/belt driven NEW GD model THE 5x6 triplex mud pump (350 gpm) on deck--New Hydraulic oil cooling system--Hydraulic driven-3 x 4 centrifical charge pump--)--Hyd. pick up winch and 2000' sandline drum--(4) hydraulic leveling jacks plus (2) Hydraulic locking safety jacks--Swing out control panel-Rauch pipe spinner--5 1/2 x 35' hex kelly w/saver sub.
NEW installed GD model THE triplex mud pump--Rebuilt swing out control panel--New hydraulic oil cooling system.
INCLUDED WITH RIG:
3 1/2" x 35' hex kelly w/saver sub
3 1/2IF x 4' reamer
3 1/2IF x 3 1/2 Reg box to box bit sub.
3 1/2IF x 4 1/2" Reg bit sub.
3 1/2IF hoist plug.
3 1/2 forkeddrill pipe slip.

AVAIL AT EXTRA COST:
2300' + or - of good used 3 1/2" x 30' even lengths custom made Aluminum drill pipe with steel tool joints slotted for breakout. ADD:$46,000. NOTE: If the drill pipe is bought along with the rig the price would be: $700,000.
(1) used back up powered GD model THE 5x6 triplex pump powered through truck PTO. Unit is mounted on a tandem axle truck w/ enclosed box bed. ADD: $60,000.
No drill collars available.

 (4) axle Crane Carrier p/b C-13 Cat.
1378-3 Gus Pech 1300 Brat 2003

 PRICE REDUCED TO: $99,000 This is a one owner unit and is still in regular service.

12" tube style mast--Two way cross top head slide--Planetary top head drive--GP-1300 hydrostatic tophead drive 0-65 RPM @ 13,000 ft lbs. 0-145 RPM @ 5828 ft. lbs. torque--24' stroke, cable, hydraulic cylinder actuated pulldown/retract drill system (pulldown 18,400 lbs/retract 24,500 lbs.--Pulldown/holdback feed control system--Two Speed retract--Dual hydraulic pump drive system with enlarged gear pumps for increased speed--Oil cooling system--Standard lighting (2)--Tower tool carrier for transportation--(4) hydraulic leveling jacks--Angle drilling lower tower supports--Hydraulic slide base--Hydraulic jib boom and extension-Hydraulic lowering tool guide with hydraulic tool clamp (enlarged to hadle 8 1/4" ID augers--2000 lb. (first layer) GP winch with large dameter drum, with headache ball, 1/4" x 150' cable--12,000 lb. (first layer) Pullmaster winch w/rapid reverse, 1/2" x 200' cable with swivel hook on jib boom--Diedrich sample hammer system--Stationary drill rod rack (10') with hammer holder for NWJ rods--Special 5' rod rack under 10' rod rack for 20 AWJ rods--Swing around auger racks (2) under both sides of rig--Swing around auger rack, rear mounted as per basic rig--2 1/2" U-joint attachment with 2" adapter--(2) sets auger guide bushing (8 1/4" ID)--Cotta heavy duty transfer case system.
18,200 hours--New engine at 12,900 hours (5300 hours on engine.



 Rig is mounte on and powered by 2003 Sterling w/Cat engine
